Fiber Optic Cables

Overview Specifications

Mechanical
  • Dimensions:
    Cable: 0.71 cm (0.28") diameter,
    Terminations: 2.54 cm (1.0") square.
  • Length:
    20cm to 500m
  • Minimum bend radius:
    3 cm momentary
    7 cm long-term

  • Weight:
    100g + 40g/meter, ~ neutrally buoyant in water.
  • Seals:
    Bulkhead end: Parker 2-009 piston seal, Collector End: HOBI Labs collector.
  • Construction:
    Quartz fiber with stainless steel shield, Kevlar braid and polyurethane jacket
  • Load Capacity:
    200 lbs static with optional strain relief.




Optical

  • Fiber type:
    200 µm silica core, step-index silica cladding, polyimide jacket; 0.22 NA; high-OH for improved UV transmission
  • Useable Wavelength Range:
    200nm to 1300nm
  • Attenuation:
    3-meter cable has < 10% attenuation from 300 to 900nm; < 50% from 200 to 1300 nm

Plot of Attenuation Versus Wavelength

Environmental

  • Operating Temperature:
    0 to 85 C
  • Maximum Depth:
    200 m
